Services
Services &
Capabilities
- General job shop work
- One-off prototype’s
- Fixture design
- Fixture building
- Small to medium production runs
- Inspection
MORE ABOUT OUR SERVICES, CAPABILITIES & EQUIPMENT: engineer impactful value for standards compliant e-services. Completely conceptualize dynamic opportunities through granular experiences. Dramatically fabricate e-business ROI and compelling quality vectors. Professionally facilitate unique sources whereas distributed sources. Objectively re-engineer fully researched total linkage and sticky internal or “organic” sources.
Equipment List
DN Solutions DVF 5000 - 5 Axis VMC
- 18,000 RPM
- X 24.6” Y 17.7” Z 15.7” B +130° – 30° C 360°
- 120 tool ATC
- 8 pallet AWC
- Renishaw RTS
- Renishaw RMP-600
- More
DN Solutions DNM 5700L - 4 Axis VMC
- 12,000 RPM
- X 51.18” Y 22.4” Z 20.1”
- 30 tool ATC
- Tsudakoma RWA-250 4th axis
- Renishaw OTS
- Renishaw OMP-600
4th and 5th Axis Fixturing
- 3 Jaw chuck on 96MM RockLock
- 9” X 24” Trunnion table witch 5th Axis 96MM RockLock multi position base
- 4th axis 6” X 6” X 30” tombstone fixture
- 5th Axis 96MM RockLock zero-point base
- 5th Axis 96MM RockLock multi position base.
- 5th Axis 69MM RockLock 90deg trunnion
- 5th Axis ER40 Collet Chuck
- 5th Axis DV56 dual station vise
- 5th Axis V562M self-centering vise
- 5th Axis V562X self-centering vise
- 5th Axis R96-DM12 dovetail fixture
- 5th Axis RL52A-A96 96MM to 52MM RockLock adaptor
- Kurt DX6 vise with 96MM RockLock pull studs integrated
- 3 Orange Vise 4”X6” self-centering vise
- 2 Orange Vise 4”X9” self-centering vise
- 4 Orange Vise 4”X12” self-centering vise
- Pierson Workholding Rotovise Pro. 4 Station 4th Axis Rotary Vise System.
- 5C Collet Chuck
Cincinnati Milacron Avenger 250T - 2 Axis Lathe
- Max Swing – 11.55″
- Max Tailstock Position – 23.5″
- Chuck Size – 10″
- Cross Travel (X-Axis) – 7.09″
- Longitudinal Travel (Z-Axis) – 20.87″
- Spindle Bore – 2.56”
- Spindle Horsepower – 30 HP
Galaxy manual lathe
- Max length of turning – 50”
- Turning diameter over bed – 20.5”
- Turning diameter over cross slide – 11.8”
- Spindle bore – 2.1”
- 10 HP
- 12” 3 jaw chuck
- 16” 4 jaw chuck
- 18” faceplate
- 8” Steady rest
- 12” Steady rest
Lancer manual lathe
- Max turning length – 20”
- Turning diameter over bed – 12”
- Max turning diameter over cross slide – 7”
- Spindle bore – 1.4”
- 3 HP
- 8” 3 jaw chuck
- 5C collet chuck
Webb Knee Mill
- X 31” Y14” Z14”
Sunnen Rod Hone
Vevor Tapping arm
Cosen C-320NC
NC Auto Saw
12.6”X15” Rectangle & 12.6” Round cut capacity
30-Watt Fiber Laser
- 200 MM X 200 MM
DoALL D-8 Surface Grinder
- 8” X 17” Magnetic Capacity
Vulcan 3-1750 Heat Treat Furnace
- 14” X 12” X 10” Inside Capacity
- 1750° F
DMG Mori Microset Uno 20/40 Tool Presetter
- Cat40 & Cat50 Current Measuring ability
JD Squared MAD 4’ X 4’
- CNC Plasma table
- Up to 3/4” plate
- 4th axis rotary plasma cutting up to 3” OD
JD Squared Model 54 Tube Bender
- Up to 1-1/2” OD solid
- Up to 2” OD X .250” wall
- Up to 3” OD X .120” wall
MR Deburr
- 3 ft.³ Vibratory Finishing Tumbler
- Inside tank dimensions: Length 31″ x Depth 13″ x Width 13.5″
Brown & Sharpe Xcel 10-7-10 CMM
- X27.6” Y39.4” Z27.6”
